Load flow studies are used to predict normal current flows and voltages. They are also used to determine voltage levels that will result from motor starting or other transient loading conditions. These results can be used to adjust transformer tap settings or take other measures that will avoid problems due to under or over voltage.

Load Flow Studies calculate the voltage drop on each feeder and transformer branch, voltage on each bus, projected power flow, and losses in the power system.

We will:

Calculate bus voltage, voltage angle, and voltage drop at each bus

Calculate branch voltage drop, power flow in kW, kVAR, kVA, Amps and power factor

Calculate branch loss in kW, kVAR, kVA, and total system losses

A detailed report is provided that includes: A full description of the basis, purpose and scope of the study. Tabulations of the data used to model system components and a corresponding one-line diagram. Descriptions of the scenarios evaluated and identification of the scenario used to evaluate load flow. Tabulations of load flow. The tabulation identifies bus voltage, voltage angle, and voltage drop at each bus; branch voltage drop, power flow in kW, kVAR, kVA, Amps and power factor; branch loss in kW, kVAR, kVA, and total system losses
